chironpy

Endurance sports analysis library for Python

Introduction

chironpy is a Python library designed for analyzing endurance sports data. It supports various file formats, including .fit, .gpx, .json and the Strava API, providing a standardized interface for processing and analyzing workout data.

The project is currently very beta state-features might be added, removed or changed in backwards incompatible ways. A stable version will be released when ready. Get in touch with the maintainers or create an issue if you have problems/questions/feature requests/special use cases.

This is a maintained fork of the original sweatpy project, which no longer seems to be maintained.

Documentation for the original project can be found here. The original sweatpy functions were generally targeted at analysing cycling workouts, chironpy emphasizes long distance running, though there is plenty of overlap so sweatpy was a great starting point.

Installation

This library can be installed from PyPI:

pip install chironpy

The WorkoutData Class

At the core of chironpy is the WorkoutData class. It provides a standardized structure for representing workouts and includes built-in methods for computing metrics, smoothing data, and extracting performance intervals.

Key Features

  • Standardized data structure from multiple supported file formats (e.g. .fit, .gpx) and the Strava API.
  • Wraps the pandas.DataFrame so can be analysed and manipulated like a df.
  • Standardized columns for speed, power, heartrate, cadence, etc. See supported columns in nomenclature
  • Resamples actvity data at 1Hz by default for clean time-series analysis.
  • Smoothing and bad data removal for clean time-series analysis.
  • Built-in metric computations like best time or distance based intervals, elevation gain.

Example

from chironpy import WorkoutData

# Load workout from file
data = WorkoutData.from_file("path/to/file.fit")

# Compute elevation gain
gain = data.elevation_gain()

# Get best intervals (time-based intervals)
durations = [30, 60, 120, 180, 300, 600, 1200, 1800, 3600] # in seconds
max_hr = data.best_intervals(durations, "heartrate")

# Get best intervals (disatnce-based intervals)
distances = [1000, 5000, 10000, 21100] # in metres
max_hr_by_distance = data.best_distance_intervals(distances, "heartrate")
fastest = data.fastest_distance_intervals(distances)

More information about running metrics can be found here.

The data frames that are returned by chironpy WorkoutData when loading files is similar for different file types. Read more about this standardization here.

The Workout class (FUTURE)

A future release will introduce a top-level Workout class. The WorkoutData class shall be provided as an attribute of new class. The Workout class extends workout data with context such as athlete data (ie training zones, threshold) to provide and other handy features.

from chironpy import Workout, Athlete

workout = Workout.from_file("path/to/file.fit")
data = workout.data # this is the WorkoutData object

# Example usage
workout.sport
workout.create_athlete(Athlete(name="Clive Gross"))
workout.athlete # this is the Athlete object
workout.laps # this is a Laps object (pandas.DataFrame)
workout.time_in_zones
workout.data['power'] # Skiba running power
workout.stress_score

Legacy Support

The original sweatpy data and analysis functions are still supported. See:

loading functions and chironpy supports loading .fit, .tcx and .gpx files. To load a .fit file:

Contributing

See contributing.

Contributors

Original authors (sweatpy):

With thanks to:

Changelog

See CHANGELOG.md for a full list of changes and version history.

License

See LICENSE file.
